YHZS35 mobile concrete batching plant manufacturer in China
Mobile Concrete Batching Plant Of Introduction
Hauling type mobile concrete mix plant adopts the semi-pulling design. With running system and standard traction pin, YHZS series hauling type mobile concrete mix plant can be dragged by a tractor, which enables convenient and quick movement and installation without foundation and debugging. It takes only one day from installation to operation.
The Mobile concrete mixing plant is widely used in small and medium construction products, road, bridge project, and concrete prefabrication factory.
YHZS35 Concrete Mixing Plant Main Features
1. It is very convenient to move from one site to another, so people who have many construction projects prefer mobile type concrete batching plant than the stationary type.
2. Easy installation. During installation, if the ground is flat and solid, it can be produced on the same day without foundation, and it is suitable for units that require tight schedules.
3. The whole machine adopts computer control, which can be operated automatically or manually. The operation is simple and easy to master.
YHZS35 Concrete Mix Plant parameter:
| project | YHZS25 | YHZS35 | YHZS50 | YHZS60 | YHZS75 |
| Maximum productivity | 25m3/h | 35m3/h | 50m3/h | 60m3/h | 75m3/h |
| Mixer model | JS750 | JS750 | JS1000 | JS1000 | JS1500 |
| Batcher model | PLD800 | PLD1200 | PLD1600 | PLD1600 | PLD2400 |
| Conveyer capacity of belt conveyer(t/h) | 200 | 200 | 400 | 400 | 400 |
| Drag speed(km/h) | 15 | 15 | 15 | 15 | 15 |
| Wheelbase (lateral) (mm) | 2800 | 3200 | 3400 | 3400 | 3400 |
| Turning radius (mm) | 11 | 15 | 15 | 15 | 15 |
| Total power (kW) | 35 | 38 | 60 | 85 | 90 |
| Unloading height (m) | 4 | 4 | 4 | 4 | 4 |
FAQ
Question I.What is the function of the concrete batch plant?
Answer: It is used to produce all kinds of concrete to meet the building work of buildings,bridges,dock,airport, railway,etc
Question II. How to choose the suitable model of batch plant?
Answer:Just tell us the capacity (m3/h,t/h)of concrete you want to produce concrete per hour or per month.
Question III.What paymet terms you use?
Answer:Usually the world most common used T/T,L/C ,etc
